Induction Cap Sealers

MICS-1.5
The MICS-1.5 is an automatic induction sealing machine encompassing a highly efficient and reliable induction generator and sealing head. This machine is designed to be located over a conveyor line and due to its compact design it can be placed into as little as half metre of conveyor. Built-in casters provide excellent mobility between production lines.

With a standard sealing head Ø15mm-Ø65mm caps can be sealed at variable power 0.15kW – 1.5 kW. Smart circuits ensure consistent sealing results regardless of the number of caps moving beneath the sealing head at any one time.

The sealing head is height and depth adjustable to fit most production lines. Also it is adjustable in two axes therefore sealing head levels perfectly with the line.

The MICS-1.5 utilizes a robust internal water cooling system which delivers heavy duty performance for demanding production lines and environments.

In addition Relco manufacture custom built sealing heads and ‘tunnel coils’ for particular applications and unusual closure designs.


MICS-2
The MICS-2 is a powerful self contained induction sealer designed to fit into most line arrangements without modification. Its in-built castors allow the machine to be moved easily from line to line, secured in place by use of the adjustable feet and plugged in to the nearest 200v-240v single phase mains electricity supply. The 2kW solid state induction generator is housed in an IP55 rated lockable enclosure. Remote start/stop option can be added for external control. Facilities are provided as standard for interlocking the sealing power of the unit to the conveyor. A flashing beacon mounted on the top of the MICS indicates operation alerts and sealing suspension.

The versatile 500mm long induction sealing head provided as standard. We designed MICS-2 to seal containers in the range of 20mm through to 110 mm of varying design without change. The seal head mounting is fully adjustable allowing for levelling with the conveyor in both planes and the ‘skewing’ of the coil to maximise exposure where necessary for larger containers. Relco also manufacture custom built sealing heads and ‘tunnel coils’ for particular applications and unusual closure designs.


MICS-3
The MICS-3 is a high power self contained induction cap sealing machine designed to fit into most line arrangements without modification. Its in-built castors allow the machine to be moved easily from line to line, secured in place by use of the adjustable feet and plugged in to the nearest 220v-240v single phase mains electricity supply. The 3KW solid state induction generator is housed in an IP55 rated lockable enclosure with a remote start/stop console for external control. Facilities are provided as standard for interlocking the sealing power of the unit to the conveyor. A flashing beacon on the top of the unit indicates that sealing power has been shut down or latched off.

The extra long 700mm induction sealing head provides more power over a greater area for improved sealing performance at higher output speeds and with wide-mouth containers. The MICS-3 is designed to seal containers in the range of 38mm through to 130mm of varying design without change parts. The seal head mounting is fully adjustable allowing for the levelling of the head to the conveyor in both planes and the ‘skewing’ of the coil to maximise exposure where necessary for larger containers. Relco also manufacture custom built sealing heads and ‘tunnel coils’ for particular applications and unusual closure designs.
